86inch Window Facing LCD Display Parameter
| Screen Size | 86" |
| Panel Technology | IPS, |
| Aspect Ratio | 16:09 |
| Native Resolution | 3,840 x 2,160 (UHD) |
| Brightness | 2,500 cd/m2 |
| Contrast Ratio | 1,200:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Surface Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Lifetime | 50,000 Hrs Min. |
| Operation Hours | 24 Hrs |
| Orientation | Landscape & Portrait |
| Input | HDMI x 2, USB |
| Output | / |
| External Control | RS232C Optional |
| Bezel Color | Black |
| Bezel Width | 18.0mm (T/B), 18.0mm (L/R) |
| Monitor Dimension (W x H x D) | 1,935.0 x 1,106.0 x 85.0 mm |
| Weight (Head) | 82.0 kg |
| Carton Dimensions (W x H x D) | 2,130 x 1,270 x 250 mm |
| Packed Weight | 94.0 kg |
| VESATM Standard Mount Interface | 400 x 600 mm, 4 x M8 |
| Operation Temperature | 0°C to 45°C |
| Operation Humidity | 10% to 80% |
| Power Type | Built-In Power |
| Power Supply | 100-240V~, 50/60Hz |
| Power Consumption | Typ. / Max. | 900 W / 1,000 W |
| Smart Energy Saving | / |
| Safety | / |
| EMC | FCC Class "A" / CE |
| Optional | Mounting Bracket: wall mount, floor stand, roof hanging |
| Basic | Remote control(w/o battery) ,AC power plug |
| | 18Month, Free spare parts, Technical support |
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in window digital screen LCD panel/LCM
since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from
the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each window
digitla screen display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The window digital screen CE-EMC Certificate of Conformity, ISO certification, FCC certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 105 or 110℃.
7.Q: What is the MOQ?
A: window digital screen sample testing is acceptable, the price is negotiable for bulk order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
